SB 203580

Pricing Availability Delivery Time Qty
Cat.No. 1202 - SB 203580 | C21H16FN3OS | CAS No. 152121-47-6
Description: Selective inhibitor of p38 MAPK
Chemical Name: 4-[5-(4-Fluorophenyl)-2-[4-(methylsulfonyl)phenyl]-1H-imidazol-4-yl]pyridine
Purity: ≥98% (HPLC)
Datasheet
Citations (86)
Reviews
Literature
Pathways

Biological Activity

Selective inhibitor of p38 MAPK (IC50 values are 50 and 500 nM for SAPK2a/p38 and SAPK2b/p38β2 respectively). Displays 100-500-fold selectivity over LCK, GSK-3β and PKBα. Shown to inhibit IL-2-induced T cell proliferation, cyclooxygenase-1 and -2, and thromboxane synthase. Enhances clonal growth of skin epithelial progenitor cells; stimulates neural stem cell (NSC) proliferation. Essential component of medium for maintaining stem cells in naive pluripotent state.

Available as part of the MAPK Cascade Inhibitor Tocriset™ and MAPK Inhibitor Tocriset™. Water-soluble Salt also available.

Licensing Information

Sold with the permission of GlaxoSmithKline

Compound Libraries

SB 203580 is also offered as part of the Tocriscreen Plus and Tocriscreen Stem Cell Toolbox. Find out more about compound libraries available from Tocris.

Technical Data

M. Wt 377.44
Formula C21H16FN3OS
Storage Desiccate at +4°C
Purity ≥98% (HPLC)
CAS Number 152121-47-6
PubChem ID 176155
InChI Key CDMGBJANTYXAIV-UHFFFAOYSA-N
Smiles CS(=O)C1=CC=C(C=C1)C1=NC(=C(N1)C1=CC=NC=C1)C1=CC=C(F)C=C1

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

All Tocris products are intended for laboratory research use only.

Solubility Data

Solvent Max Conc. mg/mL Max Conc. mM
Solubility
DMSO 9.44 25
1eq. HCl 37.74 100

Preparing Stock Solutions

The following data is based on the product molecular weight 377.44. Batch specific molecular weights may vary from batch to batch due to solvent of hydration, which will affect the solvent volumes required to prepare stock solutions.

Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
1 mM 2.65 mL 13.25 mL 26.49 mL
5 mM 0.53 mL 2.65 mL 5.3 mL
10 mM 0.26 mL 1.32 mL 2.65 mL
50 mM 0.05 mL 0.26 mL 0.53 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.
=
x
x
g/mol

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and SDS / CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Dilution Calculator

Calculate the dilution required to prepare a stock solution.
x
=
x

Product Datasheets

Certificate of Analysis / Product Datasheet
Select another batch:
Safety Datasheet

References

References are publications that support the biological activity of the product.

Borsch-Haubold et al (1998) Direct inhibition of cyclooxygenase-1 and -2 by the kinase inhibitors SB 203580 and PD 98059. J.Biol.Chem. 273 28766 PMID: 9786874

Davies et al (2000) Specificity and mechanism of action of some commonly used protein kinase inhibitors. Biochem.J. 351 95 PMID: 10998351

Saklatvala et al (1996) Role for p38 mitogen-activated protein kinase in platelet aggregation caused by collagen on a thromboxane analogue. J.Biol.Chem. 271 6586 PMID: 8636072

Sato et al (2008) Inhibitors of p38 mitogen-activated protein kinase enhance proliferation of mouse neural stem cells. J.Neurosci.Res. 86 2179 PMID: 18338804

Gafni et al (2013) Derivation of novel human ground state naive pluripotent stem cells. Nature 504 282 PMID: 24172903


If you know of a relevant reference for SB 203580, please let us know.
