Description: Selective ALK2 inhibitor
Chemical Name: 4-[6-[4-(1-Methylethoxy)phenyl]pyrazolo[1,5-a]pyrimidin-3-yl]-quinoline
Purity: ≥98% (HPLC)
Citations (50)
Reviews (3)
Literature (4)
Pathways (1)

Biological Activity for DMH-1

DMH-1 is a selective inhibitor of bone morphogenic protein (BMP) type-I receptor activin receptor-like kinase 2 (ALK2) receptor (IC50 = 108 nM or 12.6 nM in in vitro kinase assays). DMH-1 exhibits 6- and 19-fold selectivity for ALK-2 over ALK-1 and ALK-3, respectively, and no significant inhibition of AMPK, ALK5, KDR (VEGFR-2) or PDGFRβ receptors. DMH-1 blocks BMP4-induced phosphorylation of Smads 1, 5 and 8 in HEK293 cells. Promotes neurogenesis in human induced pluripotent stem cells (iPSCs) when used in combination with SB 431542 (Cat. No. 1614). DMH-1 suppresses lung cancer cell proliferation, migration, invasion in vitro and reduces tumor growth in a mouse lung cancer xenograft model. DMH-1 inhibits cellular autophagy responses. DMH-1 induces intestinal differentiation in human intestinal organoids (hIOs) derived from human pluripotent stems cells (hPSCs). The compound can also be used in protocols for the chemical reprogramming of somatic cells to iPSCs.

Compound Libraries for DMH-1

DMH-1 is also offered as part of the Tocriscreen 2.0 Max, Tocriscreen Kinase Inhibitor Library and Tocriscreen Stem Cell Library. Find out more about compound libraries available from Tocris.

Technical Data for DMH-1

M. Wt 380.44
Formula C24H20N4O
Storage Store at +4°C
Purity ≥98% (HPLC)
CAS Number 1206711-16-1
PubChem ID 50997747
Smiles CC(C)OC(C=C3)=CC=C3C(C=N2)=CN1C2=C(C4=CC=NC5=C4C=CC=C5)C=N1

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

Tocris products are intended for laboratory research use only, unless stated otherwise.

Solubility Data for DMH-1

Solvent Max Conc. mg/mL Max Conc. mM
DMSO 7.61 20

Preparing Stock Solutions for DMH-1

The following data is based on the product molecular weight 380.44. Batch specific molecular weights may vary from batch to batch due to the degree of hydration, which will affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:
Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
0.2 mM 13.14 mL 65.71 mL 131.43 mL
1 mM 2.63 mL 13.14 mL 26.29 mL
2 mM 1.31 mL 6.57 mL 13.14 mL
10 mM 0.26 mL 1.31 mL 2.63 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Dilution Calculator

Calculate the dilution required to prepare a stock solution.

Product Datasheets for DMH-1

Certificate of Analysis / Product Datasheet
Select another batch:

References for DMH-1

References are publications that support the biological activity of the product.

Bowman and Zon (2010) Swimming into the future of drug discovery: in vivo chemical screens in zebrafish. ACS Chem.Biol. 5 159 PMID: 20166761

Hao et al (2010) In vivo structure-activity relationship study of dorsomorphin analogues identifies selective VEGF and BMP inhibitors. ACS Chem.Biol. 5 245 PMID: 20020776

Neely et al (2012) DMH1, a highly selective small molecule BMP inhibitor, promotes neurogenesis of hiPSCs: comparison of PAX6 and SOX1 expression during neural induction. ACS Chem.Neurosci. 3 482 PMID: 22860217

Mohedas et al (2013) Development of an ALK2-biased BMP type I receptor kinase inhibitor. ACS Chem.Biol. 8 1291 PMID: 23547776

Hao et al (2014) DMH1, a small molecule inhibitor of BMP type i receptors, suppresses growth and invasion of lung cancer. PLoS One 9 e90748 PMID: 24603907

Sheng et al (2015) DMH1 (4-[6-(4-isopropoxyphenyl)pyrazolo[1,5-a]pyrimidin-3-yl]quinoline) inhibits chemotherapeutic drug-induced autophagy. Acta Pharmacol.Sinica 5 330 PMID: 26579463

Jung et al (2018) In vitro and in vivo imaging and tracking of intestinal organoids from human induced pluripotent stem cells. FASEB J. 32 111 PMID: 28855280

Guan et al (2022) Chemical reprogramming of human somatic cells to pluripotent stem cells. Nature 605 325 PMID: 35418683

If you know of a relevant reference for DMH-1, please let us know.

View Related Products by Product Action

View all BMP and Other Activin Receptor Inhibitors

Keywords: DMH-1, DMH-1 supplier, selective, activin, receptors, alk2, acvr1, bmp, type, I, bone, morphogenic, morphogenetic, protein, iPSC, neurogenesis, antiproliferative, differentiation, organoid, induced, pluripotent, stem, cells, reprogramming, BMP, and, Other, Activin, Receptors, ESCs, Stem, Cell, Reprogramming, 4126, Tocris Bioscience

50 Citations for DMH-1

Citations are publications that use Tocris products. Selected citations for DMH-1 include:

Vermilyea et al (2017) Induced Pluripotent Stem Cell-Derived Dopaminergic Neurons from Adult Common Marmoset Fibroblasts. Stem Cells Dev 26 1225 PMID: 28635509

Mou et al (2016) Dual SMAD Signaling Inhibition Enables Long-Term Expansion of Diverse Epithelial Basal Cells Cell Stem Cell 19 217 PMID: 27320041

Lu et al (2016) Generation of serotonin neurons from human pluripotent stem cells. Nat Biotechnol 34 89 PMID: 26655496

Liu et al (2013) Directed differentiation of forebrain GABA interneurons from human pluripotent stem cells. Nat Protoc 8 1670 PMID: 23928500

F et al (2022) P97/VCP ATPase inhibitors can rescue p97 mutation-linked motor neuron degeneration. Brain Commun 4 fcac176 PMID: 35865348

Shaochen et al (2022) Isolation and Expansion of Primary Conjunctival Stem Cells (CjSCs) from Human and Rabbit Tissues. Bio Protoc 12 PMID: 36618088

Cheng et al (2022) Genome-wide identification of the genetic basis of amyotrophic lateral sclerosis. Neuron 110 992-1008.e11 PMID: 35045337

Mary Lou et al (2022) A multimodal iPSC platform for cystic fibrosis drug testing. Nat Commun 13 4270 PMID: 35906215

Simon C et al (2022) Engineering rotating apical-out airway organoid for assessing respiratory cilia motility. iScience 25 104730 PMID: 35942088

Ming et al (2022) Recapitulating human cardio-pulmonary co-development using simultaneous multilineage differentiation of pluripotent stem cells. Elife 11 PMID: 35018887

Yan et al (2022) Fast generation of forebrain oligodendrocyte spheroids from human embryonic stem cells by transcription factors. iScience 25 105172 PMID: 36217550

Kalpaj R et al (2022) A Novel Bioreactor for Reconstitution of the Epithelium and Submucosal Glands in Decellularized Ferret Tracheas. Cells 11 PMID: 35326478

Tata et al (2018) Myoepithelial Cells of Submucosal Glands Can Function as Reserve Stem Cells to Regenerate Airways after Injury. Cell Stem Cell 22 668 PMID: 29656943

Levardon et al (2018) Expansion of Airway Basal Cells and Generation of Polarized Epithelium. Bio Protoc 8 PMID: 30009215

Wang et al (2018) The COPII cargo adapter SEC24C is essential for neuronal homeostasis. J Clin Invest 128 3319 PMID: 29939162

Li et al (2018) Fast Generation of Functional Subtype Astrocytes from Human Pluripotent Stem Cells. Stem Cell Reports 11 998 PMID: 30269954

Sheng et al (2018) A stably self-renewing adult blood-derived induced neural stem cell exhibiting patternability and epigenetic rejuvenation. Nat Commun 9 4047 PMID: 30279449

Martínez et al (2015) The BMP Pathway Participates in Human Naive CD4+ T Cell Activation and Homeostasis. Cell 10 e0131453 PMID: 26110906

McDonald et al (2015) Myocardin-related transcription factor A regulates conversion of progenitors to beige adipocytes. Arthritis Res Ther 160 105 PMID: 25579684

Varas et al (2015) Blockade of bone morphogenetic protein signaling potentiates the pro-inflammatory phenotype induced by interleukin-17 and tumor necrosis factor-α combination in rheumatoid synoviocytes. Lab Chip 17 192 PMID: 26215036

Du et al (2015) Generation and expansion of highly pure motor neuron progenitors from human pluripotent stem cells. Nat.Commun. 6 6626 PMID: 25806427

Mark et al (2023) Axon guidance genes modulate neurotoxicity of ALS-associated UBQLN2. Elife 12 PMID: 37039476

Frith and Tsakiridis (2019) Efficient Generation of Trunk Neural Crest and Sympathetic Neurons from Human Pluripotent Stem Cells Via a Neuromesodermal Axial Progenitor Intermediate. Curr Protoc Stem Cell Biol 49 e81 PMID: 30688409

Sato et al (2019) Core Transcription Factors Promote Induction of PAX3-Positive Skeletal Muscle Stem Cells. Stem Cell Reports 13 352 PMID: 31353225

Bradley E et al (2017) Single-Cell Transcriptomic Analysis of Primary and Metastatic Tumor Ecosystems in Head and Neck Cancer. Cell 171 1611-1624.e24 PMID: 29198524

Anna et al (2015) Bone morphogenetic protein signaling promotes morphogenesis of blood vessels, wound epidermis, and actinotrichia during fin regeneration in zebrafish. FASEB J 29 4299-312 PMID: 26148971

Li et al (2013) Flow-based pipeline for systematic modulation and analysis of 3D tumor microenvironments. J Biol Chem 13 1969 PMID: 23563587

Diane K et al (2018) Astrocyte-enriched feeder layers from cryopreserved cells support differentiation of spontaneously active networks of human iPSC-derived neurons. J Neurosci Methods 294 91-101 PMID: 28746822

Masato et al (2018) Turbulence Activates Platelet Biogenesis to Enable Clinical Scale Ex Vivo Production. Cell 174 636-648.e18 PMID: 30017246

Lynch et al (2018) Submucosal Gland Myoepithelial Cells Are Reserve Stem Cells That Can Regenerate Mouse Tracheal Epithelium. Cell Stem Cell 22 653 PMID: 29656941

Thaddeus G et al (2020) In Vitro CRISPR/Cas9-Directed Gene Editing to Model LRRK2 G2019S Parkinson's Disease in Common Marmosets. Sci Rep 10 3447 PMID: 32103062

Lee J et al (2020) DNA damage accumulates and responses are engaged in human ALS brain and spinal motor neurons and DNA repair is activatable in iPSC-derived motor neurons with SOD1 mutations. Acta Neuropathol Commun 8 7 PMID: 32005289

Gerald I et al (2020) The omentum of obese girls harbors small adipocytes and browning transcripts. JCI Insight 5 PMID: 32125283

Erik M et al (2020) Multiplatform genomic profiling and magnetic resonance imaging identify mechanisms underlying intratumor heterogeneity in meningioma. Nat Commun 11 4803 PMID: 32968068

Lee J et al (2020) Human Motor Neurons With SOD1-G93A Mutation Generated From CRISPR/Cas9 Gene-Edited iPSCs Develop Pathological Features of Amyotrophic Lateral Sclerosis. Front Cell Neurosci 14 604171 PMID: 33328898

Jason et al (2020) Generation and trapping of a mesoderm biased state of human pluripotency. Nat Commun 11 4989 PMID: 33020476

Kimberly J et al (2020) BMP signaling plays a role in anterior-neural/head development, but not organizer activity, in the gastropod Crepidula fornicata. Dev Biol 463 135-157 PMID: 32389712

Jianming et al (2020) Human Bocavirus 1 Infection of Well-Differentiated Human Airway Epithelium. Curr Protoc Microbiol 58 e107 PMID: 32639683

Xiong et al (2021) Human Stem Cell-Derived Neurons Repair Circuits and Restore Neural Function Cell Stem Cell 28 112 PMID: 32966778

Duan et al (2021) An airway organoid-based screen identifies a role for the HIF1α-glycolysis axis in SARS-CoV-2 infection. Cell Rep. 37 109920 PMID: 34731648

Ying et al (2021) Airway basal stem cells generate distinct subpopulations of PNECs. Cell Rep 35 109011 PMID: 33882306

Anestis et al (2021) Generating Enteric Nervous System Progenitors from Human Pluripotent Stem Cells. Curr Protoc 1 e137 PMID: 34102038

Anestis et al (2021) In Vitro Generation of Posterior Motor Neurons from Human Pluripotent Stem Cells. Curr Protoc 1 e244 PMID: 34547185

Viktoriya et al (2021) Autologous transplant therapy alleviates motor and depressive behaviors in parkinsonian monkeys. Nat Med 27 632-639 PMID: 33649496

Jiou et al (2021) C9orf72 regulates energy homeostasis by stabilizing mitochondrial complex I assembly. Cell Metab 33 531-546.e9 PMID: 33545050

Peterson et al (2019) Activating a Reserve Neural Stem Cell Population In Vitro Enables Engraftment and Multipotency after Transplantation. Stem Cell Reports 12 680 PMID: 30930245

Hackland et al (2019) FGF Modulates the Axial Identity of Trunk hPSC-Derived Neural Crest but Not the Cranial-Trunk Decision. Stem Cell Reports 12 920 PMID: 31091435

Harikrishna et al (2019) Dual TGFβ/BMP Pathway Inhibition Enables Expansion and Characterization of Multiple Epithelial Cell Types of the Normal and Cancerous Breast. Mol Cancer Res 17 1556-1570 PMID: 30992305

Nadine et al (2019) Endothelial Calcineurin Signaling Restrains Metastatic Outgrowth by Regulating Bmp2. Cell Rep 26 1227-1241.e6 PMID: 30699351

Ibon et al (2019) Derivation of Neural Stem Cells from Human Parthenogenetic Stem Cells. Methods Mol Biol 1919 43-57 PMID: 30656620

Do you know of a great paper that uses DMH-1 from Tocris? Please let us know.

Reviews for DMH-1

Average Rating: 5 (Based on 3 Reviews.)

5 Star
4 Star
3 Star
2 Star
1 Star

Have you used DMH-1?

Submit a review and receive an Amazon gift card.

$50/€35/£30/$50CAN/¥300 Yuan/¥5000 Yen for first to review with an image

$25/€18/£15/$25CAN/¥75 Yuan/¥1250 Yen for a review with an image

$10/€7/£6/$10 CAD/¥70 Yuan/¥1110 Yen for a review without an image

Submit a Review

Filter by:

The hiPSCs were maintained with Essential 8 Flex Medium with DMH-1.
By Anonymous on 02/08/2020
Assay Type: In Vitro
Species: Human
Cell Line/Tissue: ipsc

2 μM

PMID: 29939162
review image

works great for cell line culture.
By Anonymous on 08/08/2019
Assay Type: In Vitro
Species: Human

I used it grow primary human and mouse airway basal cells

PMID: 27320041

for growing cells.
By Anonymous on 02/28/2019
Assay Type: In Vitro
Species: Human

I used it grow human airway basal cells

Literature in this Area

Tocris offers the following scientific literature in this area to showcase our products. We invite you to request* your copy today!

*Please note that Tocris will only send literature to established scientific business / institute addresses.

Stem Cell Research Product Guide

Stem Cell Research Product Guide

This product guide provides a background to the use of small molecules in stem cell research and lists over 200 products for use in:

  • Self-renewal and Maintenance
  • Differentiation
  • Reprogramming
  • Organoid Generation
  • GMP and Ancillary Material Grade Products
Stem Cells Scientific Review

Stem Cells Scientific Review

Written by Kirsty E. Clarke, Victoria B. Christie, Andy Whiting and Stefan A. Przyborski, this review provides an overview of the use of small molecules in the control of stem cell growth and differentiation. Key signaling pathways are highlighted, and the regulation of ES cell self-renewal and somatic cell reprogramming is discussed. Compounds available from Tocris are listed.

Stem Cell Workflow Poster

Stem Cell Workflow Poster

Stem cells have potential as a source of cells and tissues for research and treatment of disease. This poster summarizes some key protocols demonstrating the use of small molecules across the stem cell workflow, from reprogramming, through self-renewal, storage and differentiation to verification. Advantages of using small molecules are also highlighted.

Stem Cells Poster

Stem Cells Poster

Written by Rebecca Quelch and Stefan Przyborski from Durham University (UK), this poster describes the isolation of pluripotent stem cells, their maintenance in culture, differentiation, and the generation and potential uses of organoids.

Pathways for DMH-1

TGF-β Signaling Pathway

TGF-β Signaling Pathway

The TGF-β signaling pathway is involved in the regulation of growth and proliferation of cells along with migration, differentiation and apoptosis.
