FR 180204

Pricing Availability Delivery Time Qty
Cat.No. 3706 - FR 180204 | C18H13N7 | CAS No. 865362-74-9
Description: Selective ERK inhibitor
Chemical Name: 5-(2-Phenyl-pyrazolo[1,5-a]pyridin-3-yl)-1H-pyrazolo[3,4-c]pyridazin-3-ylamine
Purity: ≥98% (HPLC)
Datasheet
Citations (7)
Literature
Pathways

Biological Activity

Selective ERK inhibitor (IC50 values are 0.14 and 0.31 μM for ERK2 and ERK1 respectively). Displays 30-fold selectivity for ERK over p38α (IC50 = 10 μM); displays no activity against human recombinant MEK1, MKK4, IKKα, PKCα, Src, Syc and PDGFα at concentrations less than 30 μM. Also inhibits TGFβ-induced AP-1 activation in Mv1Lu cells (IC50 = 3.1 μM).

Compound Libraries

FR 180204 is also offered as part of the Tocriscreen Plus. Find out more about compound libraries available from Tocris.

Technical Data

M. Wt 327.34
Formula C18H13N7
Storage Store at +4°C
Purity ≥98% (HPLC)
CAS Number 865362-74-9
PubChem ID 11493598
InChI Key XVECMUKVOMUNLE-UHFFFAOYSA-N
Smiles NC1=NNC2=C1C=C(C3=C(C=CC=C5)N5N=C3C4=CC=CC=C4)N=N2

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

All Tocris products are intended for laboratory research use only.

Solubility Data

Solvent Max Conc. mg/mL Max Conc. mM
Solubility
DMSO 32.73 100

Preparing Stock Solutions

The following data is based on the product molecular weight 327.34. Batch specific molecular weights may vary from batch to batch due to solvent of hydration, which will affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:
Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
1 mM 3.05 mL 15.27 mL 30.55 mL
5 mM 0.61 mL 3.05 mL 6.11 mL
10 mM 0.31 mL 1.53 mL 3.05 mL
50 mM 0.06 mL 0.31 mL 0.61 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.
=
x
x
g/mol

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and SDS / CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Dilution Calculator

Calculate the dilution required to prepare a stock solution.
x
=
x

Product Datasheets

Certificate of Analysis / Product Datasheet
Select another batch:
Safety Datasheet

References

References are publications that support the products' biological activity.

Ohori et al (2005) Identification of a selective ERK inhibitor and structural determination of the inhibitor-ERK2 complex. Biochem.Biophys.Res.Comm. 336 357 PMID: 16139248

Perrett et al (2013) Signaling to Extracellular Signal-regulated Kinase from ErbB1 Kinase and Protein Kinase C. J Biol Chem. 19 288 PMID: 23754287


If you know of a relevant reference for FR 180204, please let us know.

View Related Products by Target

View Related Products by Product Action

View all ERK Inhibitors

Keywords: selective ERK inhibitors inhibits MAPK signalling signaling ERK1 ERK2 FR180204 ERK

7 Citations for FR 180204

Citations are publications that use Tocris products. Selected citations for FR 180204 include:

Shamblott et al (2016) Neurogenin 3 is regulated by neurotrophic tyrosine kinase receptor type 2(TRKB) signaling in the adult human exocrine pancreas. Cell Communication and Signaling 14 23 PMID: 27659207

You et al (2015) Inhibition of ERK1/2 down-regulates the Hippo/YAP signaling pathway in human NSCLC cells. Oncotarget 6 4357 PMID: 25738359

Wurm et al (2015) Terminal epidermal differentiation is regulated by the interaction of Fra-2/AP-1 with Ezh2 and ERK1/2. PLoS Biol 29 144 PMID: 25547114

López-Cotarelo et al (2015) A novel MEK-ERK-AMPK signaling axis controls chemokine receptor CCR7-dependent survival in human mature dendritic cells. Proc Natl Acad Sci U S A 290 827 PMID: 25425646

Liang et al (2014) δ-Opioid receptors up-regulate excitatory amino acid transporters in mouse astrocytes. Microvasc Res 171 5417 PMID: 25052197

Eckle et al (2013) HIF1A reduces acute lung injury by optimizing carbohydrate metabolism in the alveolar epithelium. J Biol Chem 11 e1001665 PMID: 24086109

Shaw and Lloyd (2012) Post-transcriptional regulation of placenta growth factor mRNA by hydrogen peroxide. Genes Dev 84 155 PMID: 22683469


Do you know of a great paper that uses FR 180204 from Tocris? If so please let us know.
