Evans Blue tetrasodium salt

Pricing Availability   Qty

Save up to 40% on RUO Reagents with BIOSPRING24 (see details)

Description: Dye for assessing cell viability and blood brain barrier permeability; also EAAT inhibitor and iGluR antagonist
Chemical Name: 6,6-[(3,3'-Dimethyl[1,1'-biphenyl]-4,4'-diyl)bis(azo)bis[4-amino- 5-hydroxy-1,3-naphthalenedisulphonic acid] tetrasodium salt
Purity: ≥90% (HPLC)
Citations (2)
Reviews (1)
Literature (1)

Biological Activity for Evans Blue tetrasodium salt

Evans Blue tetrasodium salt is a potent inhibitor of L-glutamate uptake into synaptic vesicles. Also inhibits AMPA and kainate receptor-mediated currents (IC50 values are 220 and 150 nM respectively). P2X-selective purinoceptor antagonist. Also a non-permeating dye, stains damaged plasma membrane and enters in the cytoplasm and nucleus, used for checking cell viability.

Optical Data for Evans Blue tetrasodium salt

Emission Color Red
λem 680 nm

Plan Your Experiments

Use our spectra viewer to interactively plan your experiments, assessing multiplexing options. View the excitation and emission spectra for our fluorescent dye range and other commonly used dyes.

Spectral Viewer

Spectral Viewer

Technical Data for Evans Blue tetrasodium salt

M. Wt 960.82
Formula C34H24N6Na4O14S4
Storage Store at RT
Purity ≥90% (HPLC)
CAS Number 314-13-6
PubChem ID 101102794
Smiles [Na+].[Na+].[Na+].[Na+].CC1=CC(=CC=C1\N=N\C1=C(O)C2=C(C=C1)C(=CC(=C2N)S([O-])(=O)=O)S([O-])(=O)=O)C1=CC(C)=C(C=C1)\N=N\C1=C(O)C2=C(N)C(=CC(=C2C=C1)S([O-])(=O)=O)S([O-])(=O)=O

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

Tocris products are intended for laboratory research use only, unless stated otherwise.

Solubility Data for Evans Blue tetrasodium salt

Solvent Max Conc. mg/mL Max Conc. mM
water 9.61 10

Preparing Stock Solutions for Evans Blue tetrasodium salt

The following data is based on the product molecular weight 960.82. Batch specific molecular weights may vary from batch to batch due to the degree of hydration, which will affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:
Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
0.1 mM 10.41 mL 52.04 mL 104.08 mL
0.5 mM 2.08 mL 10.41 mL 20.82 mL
1 mM 1.04 mL 5.2 mL 10.41 mL
5 mM 0.21 mL 1.04 mL 2.08 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Dilution Calculator

Calculate the dilution required to prepare a stock solution.

Product Datasheets for Evans Blue tetrasodium salt

Certificate of Analysis / Product Datasheet
Select another batch:

References for Evans Blue tetrasodium salt

References are publications that support the biological activity of the product.

Price and Raymond (1996) Evans blue antagonizes both α-amino-3-hydroxy-5-methyl-4-isoxazolepropionate and kainate receptors and modulates desensitization. Mol. Pharmacol. 50 1665 PMID: 8967991

Roseth et al (1995) Uptake of L-glutamate into rat brain synaptic vesicles: effect of inhibitors that bind specifically to the glutamate transporter. J.Neurochem. 65 96 PMID: 7790899

Wittenburg et al (1996) P2-purinoceptor antagonists:II blockade of P2-purinoceptor subtypes and ecto-nucleotidase by compounds related to Evans blue and trypan blue. Naunyn Schmiedebergs Arch.Pharmacol. 354 491 PMID: 8897453

Schurmann et al (1997) Differential modulation of AMPA receptor mediated currents by Evans Blue in postnatal rat hippocampal neurones. Br.J.Pharmacol. 121 237 PMID: 9154333

Merck Index 12 3952

If you know of a relevant reference for Evans Blue tetrasodium salt, please let us know.

Keywords: Evans Blue tetrasodium salt, Evans Blue tetrasodium salt supplier, AMPA/kainate, antagonist, Potent, inhibitors, inhibits, L-glutamate, reuptake, into, synaptic, vesicles, Selective, P2X, purinergic, purinoceptors, Glutamate, AMPA, Receptors, iGluR, Ionotropic, Kainate, EAAT, Excitatory, Amino, Acid, Transporters, GLAST, GLT-1, Monoamine, Neurotran, Labels, and, Stains, Fluorescent, Transporter, Probes, 0845, Tocris Bioscience

2 Citations for Evans Blue tetrasodium salt

Citations are publications that use Tocris products. Selected citations for Evans Blue tetrasodium salt include:

Gao et al (2018) Research articleHemolysis in human erythrocytes by Clostridium perfringens epsilon toxin requires activation of P2 receptors. Virulence 9 1601 PMID: 30277122

Uderhardt et al (2019) Resident Macrophages Cloak Tissue Microlesions to Prevent Neutrophil-Driven Inflammatory Damage. Cell 177 541 PMID: 30955887

Do you know of a great paper that uses Evans Blue tetrasodium salt from Tocris? Please let us know.

Reviews for Evans Blue tetrasodium salt

Average Rating: 5 (Based on 1 Review.)

5 Star
4 Star
3 Star
2 Star
1 Star

Have you used Evans Blue tetrasodium salt?

Submit a review and receive an Amazon gift card.

$50/€35/£30/$50CAN/¥300 Yuan/¥5000 Yen for first to review with an image

$25/€18/£15/$25CAN/¥75 Yuan/¥1250 Yen for a review with an image

$10/€7/£6/$10 CAD/¥70 Yuan/¥1110 Yen for a review without an image

Submit a Review

Filter by:

Used for injection.
By Anonymous on 06/06/2020
Assay Type: In Vivo
Species: Mouse
Cell Line/Tissue: muscle

Evans blue solution 50 μl/g body weight injection to allow imaging of necrotic tissue in muscle dystrophy mouse model

review image

Literature in this Area

Tocris offers the following scientific literature in this area to showcase our products. We invite you to request* your copy today!

*Please note that Tocris will only send literature to established scientific business / institute addresses.

Fluorescent Dyes and Probes Research Product Guide

Fluorescent Dyes and Probes Research Product Guide

This product guide provides a background to the use of Fluorescent Dyes and Probes, as well as a comprehensive list of our:

  • Fluorescent Dyes, including dyes for flow cytometry
  • Fluorescent Probes and Stains, including our new MitoBrilliantTM mitochondria stains
  • Tissue Clearing Kits and Reagents
  • Aptamer-based RNA Imaging Reagents
  • Fluorescent Probes for Imaging Bacteria
  • TSA VividTM Fluorophore Kits
  • TSA Reagents for Enhancing IHC, ICC & FISH Signals
