KN-62

Pricing Availability   Qty
Cat.No. 1277 - KN-62 | C38H35N5O6S2 | CAS No. 127191-97-3
Description: Non-competitive P2X7 antagonist
Chemical Name: 4-[(2S)-2-[(5-isoquinolinylsulfonyl)methylamino]-3-oxo-3-(4-phenyl-1-piperazinyl)propyl] phenyl isoquinolinesulfonic acid ester
Purity: ≥98% (HPLC)
Datasheet
Citations (24)
Reviews
Literature

Biological Activity

Selective, cell-permeable inhibitor of CaM kinase II (IC50 = 0.9 μM). Binds directly to the calmodulin binding site of the enzyme. Potent non-competitive antagonist at the P2X7 receptor (IC50 = 15 nM).

Technical Data

M. Wt 721.84
Formula C38H35N5O6S2
Storage Desiccate at -20°C
Purity ≥98% (HPLC)
CAS Number 127191-97-3
PubChem ID 5312126
InChI Key RJVLFQBBRSMWHX-DHUJRADRSA-N
Smiles O=S(C1=CC=CC2=C1C=CN=C2)(N(C)[C@H](C(N4CCN(C7=CC=CC=C7)CC4)=O)CC3=CC=C(OS(C5=CC=CC6=C5C=CN=C6)(=O)=O)C=C3)=O

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

Tocris products are intended for laboratory research use only, unless stated otherwise.

Solubility Data

Solvent Max Conc. mg/mL Max Conc. mM
Solubility
DMSO 72.18 100

Preparing Stock Solutions

The following data is based on the product molecular weight 721.84. Batch specific molecular weights may vary from batch to batch due to solvent of hydration, which will affect the solvent volumes required to prepare stock solutions.

Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
1 mM 1.39 mL 6.93 mL 13.85 mL
5 mM 0.28 mL 1.39 mL 2.77 mL
10 mM 0.14 mL 0.69 mL 1.39 mL
50 mM 0.03 mL 0.14 mL 0.28 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.
=
x
x
g/mol

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and SDS / CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Dilution Calculator

Calculate the dilution required to prepare a stock solution.
x
=
x

Product Datasheets

Certificate of Analysis / Product Datasheet
Select another batch:

References

References are publications that support the biological activity of the product.

Chessell et al (1998) Effects of antagonists at the human recombinant P2X7 receptor. Br.J.Pharmacol. 124 1314 PMID: 9720806

Hidaka and Yokokura (1996) Molecular and cellular pharmacology of a calcium/calmodulin-dependent protein kinase II (CaM kinase II) inhibitor, KN-62, and proposal of CaM kinase phosphorylation cascades. Adv.Pharmacol. 36 193 PMID: 8783561

Tokumitsu et al (1990) KN-62, 1-[N-O-bis(5-isoquinolinesulfonyl)-N-methyl-L-tyrosyl]-4-phenylpiperazine, a specific inhibitor of Ca2+/calmodulin-dependent protein kinase II. J.Biol.Chem. 265 4315 PMID: 2155222


If you know of a relevant reference for KN-62, please let us know.

View Related Products by Product Action

View all Purinergic (P2X) Receptor Antagonists

Keywords: KN-62, KN-62 supplier, CaM, kinase, II, inhibitors, inhibits, Non-competitive, P2X7, antagonists, Calmodulin-Activated, calmodulin-dependent, Protein, Kinase, Kinases, Ca2+, Binding, modulators, Calcium, Signaling, Signalling, Receptors, Purinergic, purinoceptors, P2X, 1277, Tocris Bioscience

24 Citations for KN-62

Citations are publications that use Tocris products. Selected citations for KN-62 include:

Ishii and Sugimura (2015) Identification of a new pharmacological activity of the phenylpiperazine derivative naftopidil: tubulin-binding drug. Cell Rep 8 42618 PMID: 25584077

Donnelly-Roberts et al (2009) Mammalian P2X7 receptor pharmacology: comparison of recombinant mouse, rat and human P2X7 receptors. Br J Pharmacol 157 1203 PMID: 19558545

Heo et al (2015) Biophysical Regulation of Chromatin Architecture Instills a Mechanical Memory in Mesenchymal Stem Cells. Sci Rep 5 16895 PMID: 26592929

Díaz-Hernández et al (2008) Inhibition of the ATP-gated P2X7 receptor promotes axonal growth and branching in cultured hippocampal neurons. Mol Cancer 121 3717 PMID: 18987356

Coba et al (2008) Kinase networks integrate profiles of N-methyl-D-aspartate receptor-mediated gene expression in hippocampus. J Biol Chem 283 34101 PMID: 18815127

Draganov et al (2015) Modulation of P2X4/P2X7/Pannexin-1 sensitivity to extracellular ATP via Ivermectin induces a non-apoptotic and inflammatory form of cancer cell death. J Cell Sci 5 16222 PMID: 26552848

Giannuzzo et al (2015) The P2X7 receptor regulates cell survival, migration and invasion of pancreatic ductal adenocarcinoma cells. J Chem Biol 14 203 PMID: 26607222

Oh et al (2015) Heterosynaptic structural plasticity on local dendritic segments of hippocampal CA1 neurons. Neuron 10 162 PMID: 25558061

Araki et al (2015) Rapid dispersion of SynGAP from synaptic spines triggers AMPA receptor insertion and spine enlargement during LTP. PLoS One 85 173 PMID: 25569349

Merino et al (2015) Glucagon Increases Beating Rate but Not Contractility in Rat Right Atrium. Comparison with Isoproterenol. Sci Rep 10 e0132884 PMID: 26222156

Cui et al (2016) Endocannabinoid dynamics gate spike-timing dependent depression and potentiation. Elife 5 e13185 PMID: 26920222

Qu et al (2016) Neurophysiological mechanisms of bradykinin-evoked mucosal chloride secretion in guinea pig small intestine. World J Gastrointest Pathophysiol 7 150 PMID: 26909238

Liu and Zhuo (2014) Loss of long-term depression in the insular cortex after tail amputation in adult mice. Mol Pain 10 1 PMID: 24398034

Guo and Feng (2012) OX2R activation induces PKC-mediated ERK and CREB phosphorylation. Exp Cell Res 318 2004 PMID: 22652455

Trabanelli et al (2012) Extracellular ATP exerts opposite effects on activated and regulatory CD4+ T cells via purinergic P2 receptor activation. J Immunol 189 1303 PMID: 22753942

Person and Raman (2010) Deactivation of L-type Ca current by inhibition controls LTP at excitatory synapses in the cerebellar nuclei. Neuron 66 550 PMID: 20510859

Kobayashi et al (2010) Human eosinophils recognize endogenous danger signal crystalline uric acid and produce proinflammatory cytokines mediated by autocrine ATP. J Immunol 184 6350 PMID: 20483787

Hu et al (2006) Potentiation of TRPV3 channel function by unsaturated fatty acids. J Cell Physiol 208 201 PMID: 16557504

Galván et al (2015) Synapse-specific compartmentalization of signaling cascades for LTP induction in CA3 interneurons. Neuroscience 290 332 PMID: 25637803

Braganhol et al (2015) Nucleotide receptors control IL-8/CXCL8 and MCP-1/CCL2 secretions as well as proliferation in human glioma cells. Biochim Biophys Acta 1852 120 PMID: 25445541

Finsterwald et al (2013) Role of salt-inducible kinase 1 in the activation of MEF2-dependent transcription by BDNF. PLoS One 8 e54545 PMID: 23349925

Bodhinathan et al (2010) Intracellular redox state alters NMDA receptor response during aging through Ca2+/calmodulin-dependent protein kinase II. J Neurosci 30 1914 PMID: 20130200

Mockett et al (2011) Calcium/calmodulin-dependent protein kinase II mediates group I metabotropic glutamate receptor-dependent protein synthesis and long-term depression in rat hippocampus. J Neurosci 31 7380 PMID: 21593322

George et al (2011) Calcium-dependent phosphorylation regulates neuronal stability and plasticity in a highly precise pacemaker nucleus. J Neurophysiol 106 319 PMID: 21525377


Do you know of a great paper that uses KN-62 from Tocris? Please let us know.

Reviews for KN-62

There are currently no reviews for this product. Be the first to review KN-62 and earn rewards!

Have you used KN-62?

Submit a review and receive an Amazon gift card.

$50/€35/£30/$50CAN/¥300 Yuan/¥5000 Yen for first to review with an image

$25/€18/£15/$25CAN/¥75 Yuan/¥1250 Yen for a review with an image

$10/€7/£6/$10 CAD/¥70 Yuan/¥1110 Yen for a review without an image

Submit a Review
