(S)-SNAP 5114

Pricing Availability Delivery Time Qty
Cat.No. 1561 - (S)-SNAP 5114 | C30H35NO6 | CAS No. 157604-55-2
Description: GABA uptake inhibitor
Chemical Name: 1-[2-[tris(4-methoxyphenyl)methoxy]ethyl]-(S)-3-piperidinecarboxylic acid
Purity: ≥98% (HPLC)
Citations (4)

Biological Activity

GABA transport inhibitor, showing selectivity for GAT-3 and GAT-2 (IC50 values are 5, 21 and 388 μM for hGAT-3, rGAT-2 and hGAT-1 respectively). Increases thalamic GABA levels and is an anticonvulsant following systemic administration in vivo.

Technical Data

M. Wt 505.61
Formula C30H35NO6
Storage Store at -20°C
Purity ≥98% (HPLC)
CAS Number 157604-55-2
PubChem ID 10458835
Smiles O=[C@]([C@@H]1CN(CCOC(C3=CC=C(OC)C=C3)(C4=CC=C(OC)C=C4)C2=CC=C(OC)C=C2)CCC1)O

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

All Tocris products are intended for laboratory research use only.

Solubility Data

Solvent Max Conc. mg/mL Max Conc. mM
DMSO 50.56 100
ethanol 25.28 50

Preparing Stock Solutions

The following data is based on the product molecular weight 505.61. Batch specific molecular weights may vary from batch to batch due to solvent of hydration, which will affect the solvent volumes required to prepare stock solutions.

Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
1 mM 1.98 mL 9.89 mL 19.78 mL
5 mM 0.4 mL 1.98 mL 3.96 mL
10 mM 0.2 mL 0.99 mL 1.98 mL
50 mM 0.04 mL 0.2 mL 0.4 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and SDS / CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Dilution Calculator

Calculate the dilution required to prepare a stock solution.

Product Datasheets

Certificate of Analysis / Product Datasheet
Select another batch:
Safety Datasheet


References are publications that support the products' biological activity.

Borden et al (1994) Cloning of the human homologue of the GABA transporter GAT-3 and identification of a novel inhibitor with selectivity for this site. Receptors Channels 2 207 PMID: 7874447

Borden (1996) GABA transporter heterogeneity: pharmacology and cellular localization. Neurochem.Int. 29 335 PMID: 8939442

Dalby (2000) GABA-level increasing and anticonvulsant effects of three different GABA uptake inhibitors. Neuropharmacology 39 2399 PMID: 10974324

If you know of a relevant reference for (S)-SNAP 5114, please let us know.

View Related Products by Target

View Related Products by Product Action

View all GABA Inhibitors

Keywords: (S)-SNAP 5114, supplier, GABA, reuptake, inhibitors, inhibits, BGT-1, GAT-2, GAT-3, Transporters, Monoamine, Neurotransmitter, (S)-SNAP5114, GABA, Transporters, GABA, Transporters, Tocris Bioscience

4 Citations for (S)-SNAP 5114

Citations are publications that use Tocris products. Selected citations for (S)-SNAP 5114 include:

Kinney (2005) GAT-3 transporters regulate inhibition in the neocortex. Mol Pain 94 4533 PMID: 16135550

Patel et al (2016) Context-Dependent Modulation of GABAAR-Mediated Tonic Currents. J Physiol 36 607 PMID: 26758848

Kékesi et al (2015) Recurrent seizure-like events are associated with coupled astroglial synchronization. J Neurosci 9 215 PMID: 26150770

Kersanté et al (2013) A functional role for both -aminobutyric acid (GABA) transporter-1 and GABA transporter-3 in the modulation of extracellular GABA and GABAergic tonic conductances in the rat hippocampus. J Neurophysiol 591 2429 PMID: 23381899

Do you know of a great paper that uses (S)-SNAP 5114 from Tocris? If so please let us know.

Reviews for (S)-SNAP 5114

There are currently no reviews for this product. Be the first to review (S)-SNAP 5114 and earn rewards!

Have you used (S)-SNAP 5114?

Submit a review and receive an Amazon gift card.

$10US/$10CAN/€7/£6 gift card for a review without an image

$25US/$25CAN/€18/£15 gift card for a review with an image

*Offer only valid in the USA / Canada, UK and Europe

Submit a Review
