NU 7026

Pricing Availability   Qty
Description: Selective DNA-PK inhibitor
Chemical Name: 2-(4-Morpholinyl)-4H-naphthol[1,2-b]pyran-4-one
Purity: ≥98% (HPLC)
Citations (14)
Reviews (1)
Literature (2)

Biological Activity for NU 7026

NU 7026 is an ATP-competitive inhibitor of DNA-dependent protein kinase (DNA-PK). Displays selectivity over other PIKK family enzymes (IC50 values are 0.23, 13.0, > 100 and > 100 μM for DNA-PK, PI3K, ATM and ATR respectively). Radiosensitizes both proliferating and quiescent mouse embryonic fibroblast cells to IR and inhibits DSB repair.

Technical Data for NU 7026

M. Wt 281.31
Formula C17H15NO3
Storage Store at +4°C
Purity ≥98% (HPLC)
CAS Number 154447-35-5
PubChem ID 9860529
Smiles O=C2C1=CC=C3C(C=CC=C3)=C1OC(N4CCOCC4)=C2

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

Tocris products are intended for laboratory research use only, unless stated otherwise.

Solubility Data for NU 7026

Solvent Max Conc. mg/mL Max Conc. mM
DMSO 2.81 10

Preparing Stock Solutions for NU 7026

The following data is based on the product molecular weight 281.31. Batch specific molecular weights may vary from batch to batch due to the degree of hydration, which will affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:
Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
0.1 mM 35.55 mL 177.74 mL 355.48 mL
0.5 mM 7.11 mL 35.55 mL 71.1 mL
1 mM 3.55 mL 17.77 mL 35.55 mL
5 mM 0.71 mL 3.55 mL 7.11 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Dilution Calculator

Calculate the dilution required to prepare a stock solution.

Product Datasheets for NU 7026

Certificate of Analysis / Product Datasheet
Select another batch:

References for NU 7026

References are publications that support the biological activity of the product.

Veuger et al (2003) Radiosensitization and DNA repair inhibition by the combined use of novel inhibitors of DNA-dependent protein kinase and poly(ADP-ribose) polymerase-I. Cancer Res. 63 6008 PMID: 14522929

Amrein et al (2007) Chlorambucil cytotoxicity in malignant B lymphocytes is synergistically increased by 2-(morpholin-4-yl)-benzo[h]chomen-4-one (NU7026)-mediated inhibition of DNA double-strand break repair via inhibition of DNA-dependent protein kinase. J.Pharmacol.Exp.Ther. 321 848 PMID: 17351105

Hollick et al (2003) 2,6-disubstituted pyran-4-one and thiopyran-4-one inhibitors of DNA-dependent protein kinase (DNA-PK). Bioorg.Med.Chem.Letts. 13 3083 PMID: 12941339

If you know of a relevant reference for NU 7026, please let us know.

View Related Products by Product Action

View all DNA-Dependent Protein Kinase Inhibitors

Keywords: NU 7026, NU 7026 supplier, Selective, DNA-dependent, protein, kinases, inhibitors, inhibits, DNA-PK, NU7026, hematopoietic, haematopoietic, stem, cells, HSC, Protein, Kinase, Checkpoint, Control, Kinases, Hematopoietic, Stem, Cells, CRISPR, Reagents, 2828, Tocris Bioscience

14 Citations for NU 7026

Citations are publications that use Tocris products. Selected citations for NU 7026 include:

Jaiswal et al (2017) ATM/Wip1 activities at chromatin control Plk1 re-activation to determine G2 checkpoint duration. EMBO J 36 2161 PMID: 28607002

You et al (2015) Nanoparticulate carbon black in cigarette smoke induces DNA cleavage and Th17-mediated emphysema. Elife 4 PMID: 26437452

Dolman et al (2015) DNA-Dependent Protein Kinase As Molecular Target for Radiosensitization of Neuroblastoma Cells. PLoS One 10 e0145744 PMID: 26716839

Bohgaki et al (2011) Genomic instability, defective spermatogenesis, immunodeficiency, and cancer in a mouse model of the RIDDLE syndrome. PLoS Genet 7 e1001381 PMID: 21552324

Allen et al (2015) DNA Damage Response Proteins and Oxygen Modulate Prostaglandin E2 Growth Factor Release in Response to Low and High LET Ionizing Radiation. Front Oncol 5 260 PMID: 26697402

Rodgers et al (2015) Spatio-temporal regulation of RAG2 following genotoxic stress. DNA Repair (Amst) 27 19 PMID: 25625798

Fard et al (2013) The heterogenic final cell cycle of chicken retinal Lim1 horizontal cells is not regulated by the DNA damage response pathway. Cell Cycle 13 408 PMID: 24247150

Kanai et al (2012) Oncolytic virus-mediated manipulation of DNA damage responses: synergy with chemotherapy in killing glioblastoma stem cells. J Natl Cancer Inst 104 42 PMID: 22173583

Ando et al (2012) PIDD death-domain phosphorylation by ATM controls prodeath versus prosurvival PIDDosome signaling. Mol Cell 47 681 PMID: 22854598

Sultana et al (2013) Targeting XRCC1 deficiency in breast cancer for personalized therapy. Cancer Res 73 1621 PMID: 23253910

Petruccelli et al (2013) Expression of leukemia-associated fusion proteins increases sensitivity to histone deacetylase inhibitor-induced DNA damage and apoptosis. Mol Cancer Ther 12 1591 PMID: 23536727

Yousefzadeh et al (2014) Mechanism of suppression of chromosomal instability by DNA polymerase POLQ. PLoS Genet 10 e1004654 PMID: 25275444

Tang et al (2012) Detection of early Abl kinase activation after ionizing radiation by using a peptide biosensor. J Neurosci 13 665 PMID: 22334513

Nakahara et al (2015) Activation of NF-κB by human papillomavirus 16 E1 limits E1-dependent viral replication through degradation of E1. Chembiochem 89 5040 PMID: 25717108

Do you know of a great paper that uses NU 7026 from Tocris? Please let us know.

Reviews for NU 7026

Average Rating: 5 (Based on 1 Review.)

5 Star
4 Star
3 Star
2 Star
1 Star

Have you used NU 7026?

Submit a review and receive an Amazon gift card.

$50/€35/£30/$50CAN/¥300 Yuan/¥5000 Yen for first to review with an image

$25/€18/£15/$25CAN/¥75 Yuan/¥1250 Yen for a review with an image

$10/€7/£6/$10 CAD/¥70 Yuan/¥1110 Yen for a review without an image

Submit a Review

Filter by:

By Isabelle Cristine da Costa on 09/23/2021
Assay Type: In Vitro
Species: Human
Cell Line/Tissue: U2OS

I used the DNA-PK inhibitor (NU7026) to treat human osteosarcoma cells (U2OS) and assessed if the inhibition worked by blotting for pDNA-PKcs (S2056). The inhibitor works extremely well!
