NU 7026

Pricing Availability Delivery Time Qty
Cat.No. 2828 - NU 7026 | C17H15NO3 | CAS No. 154447-35-5
Description: Selective DNA-PK inhibitor
Chemical Name: 2-(4-Morpholinyl)-4H-naphthol[1,2-b]pyran-4-one
Purity: ≥98% (HPLC)
Datasheet
Citations (6)
Literature

Biological Activity

ATP-competitive inhibitor of DNA-dependent protein kinase (DNA-PK). Displays selectivity over other PIKK family enzymes (IC50 values are 0.23, 13.0, > 100 and > 100 μM for DNA-PK, PI3K, ATM and ATR respectively). Radiosensitizes both proliferating and quiescent mouse embryonic fibroblast cells to IR and inhibits DSB repair.

Technical Data

M. Wt 281.31
Formula C17H15NO3
Storage Store at +4°C
Purity ≥98% (HPLC)
CAS Number 154447-35-5
PubChem ID 9860529
InChI Key KKTZALUTXUZPSN-UHFFFAOYSA-N
Smiles O=C2C1=CC=C3C(C=CC=C3)=C1OC(N4CCOCC4)=C2

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

All Tocris products are intended for laboratory research use only.

Solubility Data

Solvent Max Conc. mg/mL Max Conc. mM
Solubility
DMSO 2.81 10

Preparing Stock Solutions

The following data is based on the product molecular weight 281.31. Batch specific molecular weights may vary from batch to batch due to solvent of hydration, which will affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:
Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
1 mM 3.55 mL 17.77 mL 35.55 mL
5 mM 0.71 mL 3.55 mL 7.11 mL
10 mM 0.36 mL 1.78 mL 3.55 mL
50 mM 0.07 mL 0.36 mL 0.71 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.
=
x
x
g/mol

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and SDS / CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Dilution Calculator

Calculate the dilution required to prepare a stock solution.
x
=
x

Product Datasheets

Certificate of Analysis / Product Datasheet
Select another batch:
Safety Datasheet

References

References are publications that support the products' biological activity.

Veuger et al (2003) Radiosensitization and DNA repair inhibition by the combined use of novel inhibitors of DNA-dependent protein kinase and poly(ADP-ribose) polymerase-I. Cancer Res. 63 6008 PMID: 14522929

Amrein et al (2007) Chlorambucil cytotoxicity in malignant B lymphocytes is synergistically increased by 2-(morpholin-4-yl)-benzo[h]chomen-4-one (NU7026)-mediated inhibition of DNA double-strand break repair via inhibition of DNA-dependent protein kinase. J.Pharmacol.Exp.Ther. 321 848 PMID: 17351105

Hollick et al (2003) 2,6-disubstituted pyran-4-one and thiopyran-4-one inhibitors of DNA-dependent protein kinase (DNA-PK). Bioorg.Med.Chem.Letts. 13 3083 PMID:


If you know of a relevant reference for NU 7026, please let us know.

View Related Products by Product Action

View all DNA-Dependent Protein Kinase Inhibitors

Keywords: Selective DNA-dependent protein kinases inhibitors inhibits DNA-PK NU7026 DNA-dependent Protein Kinase

6 Citations for NU 7026

Citations are publications that use Tocris products. Selected citations for NU 7026 include:

You et al (2015) Nanoparticulate carbon black in cigarette smoke induces DNA cleavage and Th17-mediated emphysema. Elife 4 PMID: 26437452

Dolman et al (2015) DNA-Dependent Protein Kinase As Molecular Target for Radiosensitization of Neuroblastoma Cells. PLoS One 10 e0145744 PMID: 26716839

Nakahara et al (2015) Activation of NF-κB by human papillomavirus 16 E1 limits E1-dependent viral replication through degradation of E1. Chembiochem 89 5040 PMID: 25717108

Fard et al (2013) The heterogenic final cell cycle of chicken retinal Lim1 horizontal cells is not regulated by the DNA damage response pathway. Cell Cycle 13 408 PMID: 24247150

Tang et al (2012) Detection of early Abl kinase activation after ionizing radiation by using a peptide biosensor. J Neurosci 13 665 PMID: 22334513

Bohgaki et al (2011) Genomic instability, defective spermatogenesis, immunodeficiency, and cancer in a mouse model of the RIDDLE syndrome. PLoS Genet 7 e1001381 PMID: 21552324


Do you know of a great paper that uses NU 7026 from Tocris? If so please let us know.
