HX 531

Pricing Availability   Qty
Cat.No. 3912 - HX 531 | C29H29N3O4 | CAS No. 188844-34-0
Description: Potent RXR antagonist
Chemical Name: 4-(7,8,9,10-Tetrahydro-5,7,7,10.10-pentamethyl-2-nitro-5H-benzo[b]naphtho[2,3-e][1,4]-diazepin-12-yl)-benzoic acid
Purity: ≥98% (HPLC)
Citations (7)
Literature (3)

Biological Activity

Potent RXR antagonist (IC50 = 18 nM). Promotes white and brown pre-adipocyte differentiation into white adipocytes. Also inhibits bexarotene-induced brown adipogenic reprogramming of myoblasts.

Compound Libraries

HX 531 is also offered as part of the Tocriscreen 2.0 Max. Find out more about compound libraries available from Tocris.

Technical Data

M. Wt 483.56
Formula C29H29N3O4
Storage Store at +4°C
Purity ≥98% (HPLC)
CAS Number 188844-34-0
PubChem ID 11755040
Smiles CC1(C)C2=C(C=C(N(C)C(C=CC([N+]([O-])=O)=C5)=C5N=C3C4=CC=C(C(O)=O)C=C4)C3=C2)C(C)(C)CC1

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

Tocris products are intended for laboratory research use only, unless stated otherwise.

Solubility Data

Solvent Max Conc. mg/mL Max Conc. mM
DMSO 9.67 20

Preparing Stock Solutions

The following data is based on the product molecular weight 483.56. Batch specific molecular weights may vary from batch to batch due to the degree of hydration, which will affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:
Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
0.2 mM 10.34 mL 51.7 mL 103.4 mL
1 mM 2.07 mL 10.34 mL 20.68 mL
2 mM 1.03 mL 5.17 mL 10.34 mL
10 mM 0.21 mL 1.03 mL 2.07 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and SDS / CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Dilution Calculator

Calculate the dilution required to prepare a stock solution.

Product Datasheets

Certificate of Analysis / Product Datasheet
Select another batch:


References are publications that support the biological activity of the product.

Ebisawa et al (1999) Retinoid X receptor-antagonistic diazepinylbenzoic acids. Chem.Pharm.Bull. 47 1778 PMID: 10748721

Alique et al (2006) Vitamin A active metabolite, all-trans retinoic acid, induces spinal cord sensitization. II. Effects after intrathecal administration. Br.J.Pharmacol. 149 65 PMID: 16847438

Suzuki et al (2009) Docosahexaenoic acid induces adipose differentiation-related protein through activation of retinoid X receptor in human choriocarcinoma BeWo cells. Biol.Pharm.Bull. 32 1177 PMID: 19571381

Nie et al (2017) Brown adipogenic reprogramming induced by a small molecule. Cell Rep. 18 624 PMID: 28099842

If you know of a relevant reference for HX 531, please let us know.

View Related Products by Target

View Related Products by Product Action

View all Retinoid X Receptor Antagonists

Keywords: HX 531, HX 531 supplier, HX531, rxrs, retinoids, x, receptors, antagonists, potent, stem, cell, differentiation, adipocytes, Retinoid, X, Receptor, 3912, Tocris Bioscience

7 Citations for HX 531

Citations are publications that use Tocris products. Selected citations for HX 531 include:

Yang et al (2017) Effects of electroacupuncture and the retinoid X receptor (RXR) signalling pathway on oligodendrocyte differentiation in the demyelinated spinal cord of rats. Acupunct Med 35 122 PMID: 27841975

Wnuk et al (2016) The Crucial Involvement of Retinoid X Receptors in DDE Neurotoxicity. PLoS Biol 29 155 PMID: 26563996

Edwards et al (2019) Assessment of total, ligand-induced peroxisome proliferator activated receptor γ ligand activity in serum. Environ Health 18 45 PMID: 31072366

Wnuk et al (2017) Benzophenone-3 Impairs Autophagy, Alters Epigenetic Status, and Disrupts Retinoid X Receptor Signaling in Apoptotic Neuronal Cells. Mol Neurobiol PMID: 28815487

Do you know of a great paper that uses HX 531 from Tocris? Please let us know.
