Guangxitoxin 1E

Pricing Availability Delivery Time Qty
Cat.No. 5676 - Guangxitoxin 1E | Glu-Gly-Glu-Cys-Gly-Gly-Phe-Trp-Trp-Lys-Cys-Gly-Ser-Gly-Lys-Pro-Ala-Cys-Cys-Pro-Lys-Tyr-Val-Cys-Ser-Pro-Lys-Trp-Gly-Leu-Cys-Asn-Phe-Pro-Met-Pro | CAS No. 1233152-82-3
Description: Potent Kv2.1 and Kv2.2 channel blocker
Datasheet
Citations
Literature

Biological Activity

Kv2.1 and Kv2.2 channel blocker (IC50 values are 1-3 nM). Enhances glucose-stimulated insulin secretion from human islets in vitro, but not from islet cells lacking the Kv2.1 channel. Has no significant effect on plasma insulin, glucagon or blood glucose levels in mice, but increases plasma somatostatin levels.

Technical Data

M. Wt 3948.61
Formula C178H248N44O45S7
Sequence EGECGGFWWKCGSGKPACCPKYVCSPKWGLCNFPMP

(Modifications: Disulfide bridge: 4-19,11-24,18-31)

Storage Store at -20°C
CAS Number 1233152-82-3
PubChem ID 121513878
InChI Key SZVUKNYCMKWHNH-UHFFFAOYSA-N
Smiles [H]N[C@@H](CCC(O)=O)C(=O)NCC(=O)N[C@@H](CCC(O)=O)C(=O)N[C@H]1CSSC[C@@H]2NC(=O)[C@@H]3CSSC[C@H](NC(=O)[C@H](CC(C)C)NC(=O)CNC(=O)[C@H](CC4=CNC5=C4C=CC=C5)NC(=O)[C@H](CCCCN)NC(=O)[C@@H]4CCCN4C(=O)[C@H](CO)NC(=O)[C@H](CSSC[C@H](NC(=O)[C@H](CCCCN)NC(=O)[C@H](CC4=CNC5=C4C=CC=C5)NC(=O)[C@H](CC4=CNC5=C4C=CC=C5)NC(=O)[C@H](CC4=CC=CC=C4)NC(=O)CNC(=O)CNC1=O)C(=O)NCC(=O)N[C@@H](CO)C(=O)NCC(=O)N[C@@H](CCCCN)C(=O)N1CCC[C@H]1C(=O)N[C@@H](C)C(=O)N3)NC(=O)[C@@H](NC(=O)[C@H](CC1=CC=C(O)C=C1)NC(=O)[C@H](CCCCN)NC(=O)[C@@H]1CCCN1C2=O)C(C)C)C(=O)N[C@@H](CC(N)=O)C(=O)N[C@@H](CC1=CC=CC=C1)C(=O)N1CCC[C@H]1C(=O)N[C@@H](CCSC)C(=O)N1CCC[C@H]1C(O)=O

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

All Tocris products are intended for laboratory research use only.

Solubility Data

SolubilitySoluble to 1 mg/ml in water

Preparing Stock Solutions

The following data is based on the product molecular weight 3948.61. Batch specific molecular weights may vary from batch to batch due to solvent of hydration, which will affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:
Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
1 mM 0.25 mL 1.27 mL 2.53 mL
5 mM 0.05 mL 0.25 mL 0.51 mL
10 mM 0.03 mL 0.13 mL 0.25 mL
50 mM 0.01 mL 0.03 mL 0.05 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.
=
x
x
g/mol

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and SDS / CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Dilution Calculator

Calculate the dilution required to prepare a stock solution.
x
=
x

Product Datasheets

Safety Datasheet

References

References are publications that support the products' biological activity.

Li et al (2013) The role of voltage-gated potassium channels Kv2.1 and Kv2.2 in the regulation of insulin and somatostatin release from pancreatic islets. J.Pharmacol.Exp.Ther. 344 407 PMID: 23161216

Herrington (2007) Gating modifier peptides as probes of pancreatic beta-cell physiology. Toxicon 49 231 PMID: 17101164


If you know of a relevant reference for Guangxitoxin 1E, please let us know.

View Related Products by Product Action

View all Voltage-gated Potassium (KV) Channel Blockers

Keywords: Guangxitoxin 1E, supplier, Kv2.1, Kv2.2, inward, rectifier, potassium, current, pancreatic, islets, beta, cells, inhibits, inhibitors, insulin, glucose, somatostatin, GxTx-1E, venoms, Voltage-Gated, Potassium, Channels, Voltage-Gated, Potassium, Channels, Tocris Bioscience

Citations for Guangxitoxin 1E

Citations are publications that use Tocris products.

Currently there are no citations for Guangxitoxin 1E. Do you know of a great paper that uses Guangxitoxin 1E from Tocris? If so please let us know.
