Agitoxin 2

Pricing Availability Delivery Time Qty
Cat.No. 5195 - Agitoxin 2 | Gly-Val-Pro-Ile-Asn-Val-Ser-Cys-Thr-Gly-Ser-Pro-Gln-Cys-Ile-Lys-Pro-Cys-Lys-Asp-Ala-Gly-Met-Arg-Phe-Gly-Lys-Cys-Met-Asn-Arg-Lys-Cys-His-Cys-Thr-Pro-Lys | CAS No. 168147-41-9
Description: Potent Shaker K+ channel blocker
Datasheet
Citations
Literature

Biological Activity

Potent Shaker K+ channel blocker (Ki = 0.64 nM). Also inhibits Kv1.3, Kv1.6 and Kv1.1 K+ channels (Ki values are 4, 37 and 44 pM respectively).

Technical Data

M. Wt 4090.87
Formula C169H278N54O48S8
Sequence GVPINVSCTGSPQCIKPCKDAGMRFGKCMNRKCHCTPK

(Modifications: Disulfide bridge: 8-28,14-33,18-35)

Storage Store at -20°C
CAS Number 168147-41-9
PubChem ID 16198951
InChI Key POIUWJQBRNEFGX-XAMSXPGMSA-N
Smiles [H]NCC(=O)N[C@@H](C(C)C)C(=O)N1CCC[C@H]1C(=O)N[C@@H]([C@@H](C)CC)C(=O)N[C@@H](CC(N)=O)C(=O)N[C@@H](C(C)C)C(=O)N[C@@H](CO)C(=O)N[C@H]1CSSC[C@@H]2NC(=O)[C@H](CCCCN)NC(=O)CNC(=O)[C@H](CC3=CC=CC=C3)NC(=O)[C@H](CCCNC(N)=N)NC(=O)[C@H](CCSC)NC(=O)CNC(=O)[C@H](C)NC(=O)[C@H](CC(O)=O)NC(=O)[C@H](CCCCN)NC(=O)[C@@H]3CSSC[C@H](NC(=O)[C@H](CC4=CNC=N4)NC(=O)[C@H](CSSC[C@H](NC(=O)[C@H](CCC(N)=O)NC(=O)[C@@H]4CCCN4C(=O)[C@H](CO)NC(=O)CNC(=O)[C@@H](NC1=O)[C@@H](C)O)C(=O)N[C@@H]([C@@H](C)CC)C(=O)N[C@@H](CCCCN)C(=O)N1CCC[C@H]1C(=O)N3)NC(=O)[C@H](CCCCN)NC(=O)[C@H](CCCNC(N)=N)NC(=O)[C@H](CC(N)=O)NC(=O)[C@H](CCSC)NC2=O)C(=O)N[C@@H]([C@@H](C)O)C(=O)N1CCC[C@H]1C(=O)N[C@@H](CCCCN)C(O)=O

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

All Tocris products are intended for laboratory research use only.

Solubility Data

SolubilitySoluble to 1 mg/ml in water

Preparing Stock Solutions

The following data is based on the product molecular weight 4090.87. Batch specific molecular weights may vary from batch to batch due to solvent of hydration, which will affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:
Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
1 mM 0.24 mL 1.22 mL 2.44 mL
5 mM 0.05 mL 0.24 mL 0.49 mL
10 mM 0.02 mL 0.12 mL 0.24 mL
50 mM 0 mL 0.02 mL 0.05 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.
=
x
x
g/mol

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and SDS / CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Dilution Calculator

Calculate the dilution required to prepare a stock solution.
x
=
x

Product Datasheets

Safety Datasheet

References

References are publications that support the products' biological activity.

Garcia et al (1994) Purification and characterization of three inhibitors of voltage-dependent K+ channels from Leiurus quinquestriatus var. hebraeus venom. Biochemistry 33 6834 PMID: 8204618

Anangi et al (2012) Recombinant expression of margatoxin and agitoxin-2 in Pichia pastoris: an efficient method for production of KV1.3 channel blockers. PLoS ONE 7 e52965 PMID: 23300835

Gross et al (1996) Agitoxin footprinting the shaker potassium channel pore. Neuron 16 399 PMID: 789954


If you know of a relevant reference for Agitoxin 2, please let us know.

View Related Products by Product Action

View all Voltage-gated Potassium (KV) Channel Blockers

Keywords: Agitoxin 2, supplier, potent, shaker, potassium, K+, channels, blockers, inhibits, inhibitors, Kv1.4, kv1.1, kv1.3, kv1.6, voltage, gated, venoms, Voltage-Gated, Potassium, Channels, Tocris Bioscience

Citations for Agitoxin 2

Citations are publications that use Tocris products.

Currently there are no citations for Agitoxin 2. Do you know of a great paper that uses Agitoxin 2 from Tocris? If so please let us know.
