OD1

Pricing Availability Delivery Time Qty
Cat.No. 5941 - OD1 | Gly-Val-Arg-Asp-Ala-Tyr-Ile-Ala-Asp-Asp-Lys-Asn-Cys-Val-Tyr-Thr-Cys-Ala-Ser-Asn-Gly-Tyr-Cys-Asn-Thr-Glu-Cys-Thr-Lys-Asn-Gly-Ala-Glu-Ser-Gly-Tyr-Cys-Gln-Trp-Ile-Gly-Arg-Tyr-Gly-Asn-Ala-Cys-Trp-Cys-Ile-Lys-Leu-Pro-Asp-Glu-Val-Pro-Ile-Arg-Ile-Pro-Gly-Lys-Cys
Description: Potent hNav1.4, rNav1.6 and rNav1.7 channel activator
Datasheet
Citations
Reviews
Literature

Biological Activity

Potent rat Nav1.7, human Nav1.4 and rat Nav1.6 channel activator (EC50 values are 7, 10 and 47 nM, respectively). Exhibits minimal activation at mammalian Nav1.2, Nav1.3 and Nav1.5 (EC50 values >3 μM). Inhibits fast inactivation on all channels. Increases peak currents at all voltages and stimulates a persistent Na+ current at hNav1.7 channel. Increases hyperpolarization at Nav1.4 and Nav1.6 channels. Induces spontaneous pain in vivo.

Technical Data

M. Wt 7206.1
Formula C308H466N90O95S8
Sequence GVRDAYIADDKNCVYTCASNGYCNTECTKNGAESGYCQWIGRYGNACWCIKLPDEVPIRIPGKCR

(Modifications: Disulfide bridge: 13-64, 17-37, 23-47, 27-49, Arg-65 = C-terminal amide)

Storage Store at -20°C
PubChem ID 123773280
InChI Key AGQDOUOEJSDDQH-BJQYWQRQSA-N
Smiles [H]NCC(=O)N[C@@H](C(C)C)C(=O)N[C@@H](CCCNC(N)=N)C(=O)N[C@@H](CC(O)=O)C(=O)N[C@@H](C)C(=O)N[C@@H](CC1=CC=C(O)C=C1)C(=O)N[C@@H]([C@@H](C)CC)C(=O)N[C@@H](C)C(=O)N[C@@H](CC(O)=O)C(=O)N[C@@H](CC(O)=O)C(=O)N[C@@H](CCCCN)C(=O)N[C@@H](CC(N)=O)C(=O)N[C@H]1CSSC[C@H](NC(=O)[C@H](CCCCN)NC(=O)CNC(=O)[C@@H]2CCCN2C(=O)[C@@H](NC(=O)[C@H](CCCNC(N)=N)NC(=O)[C@@H](NC(=O)[C@@H]2CCCN2C(=O)[C@@H](NC(=O)[C@H](CCC(O)=O)NC(=O)[C@H](CC(O)=O)NC(=O)[C@@H]2CCCN2C(=O)[C@H](CC(C)C)NC(=O)[C@H](CCCCN)NC(=O)[C@@H](NC(=O)[C@@H]2CSSC[C@@H]3NC(=O)[C@H](CC4=CC=C(O)C=C4)NC(=O)CNC(=O)[C@H](CO)NC(=O)[C@H](CCC(O)=O)NC(=O)[C@H](C)NC(=O)CNC(=O)[C@H](CC(N)=O)NC(=O)[C@H](CCCCN)NC(=O)[C@@H](NC(=O)[C@@H]4CSSC[C@H](NC(=O)[C@@H](NC(=O)[C@H](CC5=CC=C(O)C=C5)NC(=O)[C@@H](NC1=O)C(C)C)[C@@H](C)O)C(=O)N[C@@H](C)C(=O)N[C@@H](CO)C(=O)N[C@@H](CC(N)=O)C(=O)NCC(=O)N[C@@H](CC1=CC=C(O)C=C1)C(=O)N[C@@H](CSSC[C@H](NC(=O)[C@H](C)NC(=O)[C@H](CC(N)=O)NC(=O)CNC(=O)[C@H](CC1=CC=C(O)C=C1)NC(=O)[C@H](CCCNC(N)=N)NC(=O)CNC(=O)[C@@H](NC(=O)[C@H](CC1=CNC5=C1C=CC=C5)NC(=O)[C@H](CCC(N)=O)NC3=O)[C@@H](C)CC)C(=O)N[C@@H](CC1=CNC3=C1C=CC=C3)C(=O)N2)C(=O)N[C@@H](CC(N)=O)C(=O)N[C@@H]([C@@H](C)O)C(=O)N[C@@H](CCC(O)=O)C(=O)N4)[C@@H](C)O)[C@@H](C)CC)C(C)C)[C@@H](C)CC)[C@@H](C)CC)C(=O)N[C@@H](CCCNC(N)=N)C(N)=O

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

All Tocris products are intended for laboratory research use only.

Solubility Data

Solubility Soluble to 1 mg/ml in water

Preparing Stock Solutions

The following data is based on the product molecular weight 7206.1. Batch specific molecular weights may vary from batch to batch due to solvent of hydration, which will affect the solvent volumes required to prepare stock solutions.

Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
1 mM 0.14 mL 0.69 mL 1.39 mL
5 mM 0.03 mL 0.14 mL 0.28 mL
10 mM 0.01 mL 0.07 mL 0.14 mL
50 mM 0 mL 0.01 mL 0.03 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.
=
x
x
g/mol

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and SDS / CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Dilution Calculator

Calculate the dilution required to prepare a stock solution.
x
=
x

Product Datasheets

Certificate of Analysis / Product Datasheet
Select another batch:
Safety Datasheet

References

References are publications that support the biological activity of the product.

Durek et al (2013) Chemical engineering and structural and pharmacological characterization of the α-scorpion toxin OD1. ACS Chem.Biol. 8 1215 PMID: 23527544

Jalali et al (2005) OD1, the first toxin isolated from the venom of the scorpion Odonthobuthus doriae active on voltage-gated Na+ channels. FEBS Lett. 579 4181 PMID: 16038905

Maertens et al (2006) Potent modulation of the voltage-gated sodium channel Nav1.7 by OD1, a toxin from the scorpion Odonthobuthus doriae. Mol.Pharmacol. 70 405 PMID: 16641312


If you know of a relevant reference for OD1, please let us know.
