Pricing Availability   Qty
Description: Potent and selective degrader of mutant FKBP12F36V fusion proteins
Chemical Name: (R)-3-(3,4-Dimethoxyphenyl)-1-(2-(2-((7-(((S)-1-((2S,4R)-4-hydroxy-2-(((S)-1-(4-(4-methylthiazol-5-yl)phenyl)ethyl)carbamoyl)pyrrolidin-1-yl)-3,3-dimethyl-1-oxobutan-2-yl)amino)-7-oxoheptyl)amino)-2-oxoethoxy)phenyl)propyl (S)-1-((S)-2-(3,4,5-trimethoxyphenyl)butanoyl)piperidine-2-carboxylate trifluoroacetate
Purity: ≥98% (HPLC)
Citations (6)
Literature (3)

Biological Activity for dTAGV-1

dTAGV-1 is a degrader targeting mutant FKBP12F36V fusion proteins. Comprises a ligand selective for F36V single-point mutated FKBP12, a linker and a von Hippel-Lindau (VHL)-binding ligand. Induces potent and selective degradation of FKBP12F36V fusion proteins in vitro and in vivo. Selectively degrades FKBP12F36V-EWS/FLI fusion proteins and inhibits cell proliferation in FKBP12F36V-EWS/FLI-expressing Ewing sarcoma cells.

Hydrochloride salt (Cat.No. 7374) available; suitable for in vivo use.

Negative control dTAGV-1-NEG (Cat. No. 6915) also available.

FKBP12F36V can be expressed as a fusion with a target protein of interest using genome engineering techniques, via transgene expression or CRISPR-mediated locus-specific knock-in. Custom knock-in cell lines for the dTAG and aTAG platforms are available from our sister brand R&D Systems. Email TPD@bio-techne.com to enquire.

Plasmid vectors for the lentiviral expression and CRISPR-mediated knock-in of FKBP12F36V are available from Addgene.

Licensing Information

Sold under license from Dana-Farber Cancer Institute

Technical Data for dTAGV-1

M. Wt 1361.58
Formula C68H90N6O14S CF3CO2H
Storage Store at -20°C
Purity ≥98% (HPLC)
CAS Number 2624313-15-9
Smiles C[C@H](NC([C@@H]1C[C@@H](O)CN1C([C@@H](NC(CCCCCCNC(COC2=CC=CC=C2[C@H](OC([C@@H]3CCCCN3C([C@@H](CC)C4=CC(OC)=C(OC)C(OC)=C4)=O)=O)CCC5=CC(OC)=C(OC)C=C5)=O)=O)C(C)(C)C)=O)=O)C6=CC=C(C=C6)C7=C(N=CS7)C.OC(C(F)(F)F)=O

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

Tocris products are intended for laboratory research use only, unless stated otherwise.

Solubility Data for dTAGV-1

Solvent Max Conc. mg/mL Max Conc. mM
DMSO 136.16 100

Preparing Stock Solutions for dTAGV-1

The following data is based on the product molecular weight 1361.58. Batch specific molecular weights may vary from batch to batch due to the degree of hydration, which will affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:
Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
1 mM 0.73 mL 3.67 mL 7.34 mL
5 mM 0.15 mL 0.73 mL 1.47 mL
10 mM 0.07 mL 0.37 mL 0.73 mL
50 mM 0.01 mL 0.07 mL 0.15 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Dilution Calculator

Calculate the dilution required to prepare a stock solution.

Product Datasheets for dTAGV-1

Certificate of Analysis / Product Datasheet
Select another batch:

References for dTAGV-1

References are publications that support the biological activity of the product.

Nabet et al (2020) Rapid and direct control of target protein levels with VHL-recruiting dTAG molecules. Nat.Commun. 11 4687 PMID: 32948771

If you know of a relevant reference for dTAGV-1, please let us know.

Keywords: dTAGV-1, dTAGV-1 supplier, 2451573-86-5, dTAGVHL1, degraders, degrades, targeted, protein, degradation, FKBP12F36V, fusion, mutant, PROTAC, VHL, von, Hippel, Lindau, TPD, TAG, Degradation, Platform, 6914, Tocris Bioscience

6 Citations for dTAGV-1

Citations are publications that use Tocris products. Selected citations for dTAGV-1 include:

Kristian et al (2021) Generation of locus-specific degradable tag knock-ins in mouse and human cell lines. STAR Protoc 2 100575 PMID: 34151298

Tomek et al (2023) Precise modulation of transcription factor levels identifies features underlying dosage sensitivity. Nat Genet 55 841-851 PMID: 37024583

Cristian et al (2023) MYC regulates CSF-1 expression via microRNA 17/20a to modulate tumor-associated macrophages in osteosarcoma. JCI Insight PMID: 37279073

Francisca et al (2022) Systematic profiling of conditional degron tag technologies for target validation studies. Nat Commun 13 5495 PMID: 36127368

Tom et al (2022) Control of ribosomal RNA synthesis by hematopoietic transcription factors. Mol Cell 82 3826-3839.e9 PMID: 36113481

Anna-Katerina et al (2022) Generation of knock-in degron tags for endogenous proteins in mice using the dTAG system. STAR Protoc 3 101660 PMID: 36097386

Do you know of a great paper that uses dTAGV-1 from Tocris? Please let us know.

Reviews for dTAGV-1

There are currently no reviews for this product. Be the first to review dTAGV-1 and earn rewards!

Have you used dTAGV-1?

Submit a review and receive an Amazon gift card.

$50/€35/£30/$50CAN/¥300 Yuan/¥5000 Yen for first to review with an image

$25/€18/£15/$25CAN/¥75 Yuan/¥1250 Yen for a review with an image

$10/€7/£6/$10 CAD/¥70 Yuan/¥1110 Yen for a review without an image

Submit a Review

Literature in this Area

Tocris offers the following scientific literature in this area to showcase our products. We invite you to request* your copy today!

*Please note that Tocris will only send literature to established scientific business / institute addresses.

Targeted Protein Degradation Research Product Guide

Targeted Protein Degradation Research Product Guide

This brochure highlights the tools and services available from Bio-Techne to support Targeted Protein Degradation research, including:

  • Active Degraders
  • TAG Degradation Platform
  • Degrader Building Blocks
  • Ubiquitin-Proteasome System Proteins
  • Assays for Protein Degradation
Targeted Protein Degradation Poster

Targeted Protein Degradation Poster

Degraders (e.g. PROTACs) are bifunctional small molecules, that harness the Ubiquitin Proteasome System (UPS) to selectively degrade target proteins within cells. They consist of three covalently linked components: an E3 ubiquitin ligase ligand, a linker and a ligand for the target protein of interest. Authored in-house, this poster outlines the generation of a toolbox of building blocks for the development of Degraders. The characteristics and selection of each of these components are discussed. Presented at EFMC 2018, Ljubljana, Slovenia

Validating Targets for TPD Using dTAG Poster

Validating Targets for TPD Using dTAG Poster

The dTAG platform offers a generalizable strategy to degrade, in principle, any intracellular protein of interest (POI) and is a useful strategy for exploration and validation of targets. This poster presents a workflow solution for target validation, from custom TAG knock-in cell-lines for your POI, different dTAG Degraders to knockdown you POI, to automated assays for protein degradation using Simple WesternTM instruments. Data are also presented on the use of an antibody that recognizes the TAG domain (FKBP12F36V) for detection of degradation. Presented at TPD Europe, March 2022, London, UK.
