UCL 1684

Pricing Availability Delivery Time Qty
Cat.No. 1310 - UCL 1684 | C34H30Br2N4 | CAS No. 199934-16-2
Description: Highly potent blocker of KCa2
Chemical Name: 6,12,19,20,25,26-Hexahydro-5,27:13,18:21,24-trietheno-11,7-metheno-7H-dibenzo [b,n] [1,5,12,16]tetraazacyclotricosine-5,13-diium dibromide
Purity: ≥97% (HPLC)
Datasheet
Citations (11)
Literature

Biological Activity

Highly potent, non-peptidic blocker of the apamin-sensitive Ca2+-activated K+ channel (KCa2.1) (IC50 = 3 nM in rat sympathetic neurons). Blocks hKCa2.1 and rKCa2.2 channels expressed in HEK 293 cells with IC50 values of 762 and 364 pM respectively.

Licensing Information

Sold with the permission of University College, London

Technical Data

M. Wt 654.44
Formula C34H30Br2N4
Storage Desiccate at RT
Purity ≥97% (HPLC)
CAS Number 199934-16-2
PubChem ID 9852584
InChI Key KPNMQIKQVCWNTP-UHFFFAOYSA-N
Smiles C12=CC=CC=C1C(NCC4=CC=C(CNC5=CC=[N+]7C6=C5C=CC=C6)C=C4)=CC=[N+]2CC3=CC=CC(C7)=C3.[Br-].[Br-]

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

All Tocris products are intended for laboratory research use only.

Solubility Data

Solvent Max Conc. mg/mL Max Conc. mM
Solubility
DMSO 7.21 10

Preparing Stock Solutions

The following data is based on the product molecular weight 654.44. Batch specific molecular weights may vary from batch to batch due to solvent of hydration, which will affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:
Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
1 mM 1.53 mL 7.64 mL 15.28 mL
5 mM 0.31 mL 1.53 mL 3.06 mL
10 mM 0.15 mL 0.76 mL 1.53 mL
50 mM 0.03 mL 0.15 mL 0.31 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.
=
x
x
g/mol

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and SDS / CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Dilution Calculator

Calculate the dilution required to prepare a stock solution.
x
=
x

Product Datasheets

Certificate of Analysis / Product Datasheet
Select another batch:
Safety Datasheet

References

References are publications that support the products' biological activity.

Campos Rosa et al (2000) Synthesis, molecular modeling, and pharmacological testing of bis-quinolinium cyclophanes: potent, non-peptidic blockers of the apamin-sensitive Ca2+-activated K+ channel. J.Med.Chem. 43 420 PMID: 10669569

Malik-Hall et al (2000) Compounds that block intermediate-conductance (IKCa) and small-conductance (SKCa) calcium-activated potassium channels. Br.J.Pharmacol. 129 1431 PMID: 10742299

Strobaek et al (2000) Pharmacological characterization of small-conductance Ca2+-activated K+ channels stably expressed in HEK 293 cells. Br.J.Pharmacol. 129 991 PMID: 10696100


If you know of a relevant reference for UCL 1684, please let us know.

View Related Products by Product Action

View all Calcium-Activated Potassium (KCa) Channel Blockers

Keywords: UCL 1684, supplier, potent, blockers, SKCa, Potassium, Channels, K+, ca2+-activated, ca2+-dependent, SK1, SK2, UCL1684, Ca2+-Activated, Potassium, Channels, Tocris Bioscience

11 Citations for UCL 1684

Citations are publications that use Tocris products. Selected citations for UCL 1684 include:

Geier et al (2011) Dynamic interplay of excitatory and inhibitory coupling modes of neuronal L-type calcium channels. Am J Physiol Cell Physiol 300 C937 PMID: 21228322

Hilgers et al (2010) Twenty-four-hour exposure to altered blood flow modifies endothelial Ca2+-activated K+ channels in rat mesenteric arteries. J Pharmacol Exp Ther 333 210 PMID: 20040579

Lamy et al (2010) Allosteric block of KCa2 channels by apamin. PLoS One 285 27067 PMID: 20562108

Giachini et al (2009) Upregulation of intermediate calcium-activated potassium channels counterbalance the impaired endothelium-dependent vasodilation in stroke-prone spontaneously hypertensive rats. Transl Res 154 183 PMID: 19766962

Szollosi et al (2007) Glucose stimulates Ca2+ influx and insulin secretion in 2-week-old β-cells lacking ATP-sensitive K+ channels. Br J Pharmacol 282 1747 PMID: 17138557

Abdulkareem et al (2016) Knockdown of the small conductance Ca(2+) -activated K(+) channels is potently cytotoxic in breast cancer cell lines. Heart Rhythm 173 177 PMID: 26454020

Chien and Su (2015) 5-hydroxytryptamine has an endothelium-derived hyperpolarizing factor-like effect on coronary flow in isolated rat hearts. J Biol Chem 22 42 PMID: 26076928

Kurahashi et al (2014) Platelet-derived growth factor receptor-α-positive cells and not smooth muscle cells mediate purinergic hyperpolarization in murine colonic muscles. Am J Physiol Cell Physiol 307 C561 PMID: 25055825

Benton et al (2013) Iberiotoxin-sensitive and -insensitive BK currents in Purkinje neuron somata. J Neurophysiol 109 2528 PMID: 23446695

Alpert and Alford (2013) Synaptic NMDA receptor-dependent Ca2+ entry drives membrane potential and Ca2+ oscillations in spinal ventral horn neurons. PLoS One 8 e63154 PMID: 23646190

Hsueh et al (2013) Proarrhythmic effect of blocking the small conductance calcium activated potassium channel in isolated canine left atrium. J Biomed Sci 10 891 PMID: 23376397


Do you know of a great paper that uses UCL 1684 from Tocris? If so please let us know.
