Charybdotoxin

Pricing Availability Delivery Time Qty
Cat.No. 1087 - Charybdotoxin | Glp-Phe-Thr-Asn-Val-Ser-Cys-Thr-Thr-Ser-Lys-Glu-Cys-Trp-Ser-Val-Cys-Gln-Arg-Leu-His-Asn-Thr-Ser-Arg-Gly-Lys-Cys-Met-Asn-Lys-Lys-Cys-Arg-Cys-Tyr-Ser-OH (Disulfide bridge: 7-28, 13-33 and 17-35) | CAS No. 95751-30-7
Description: KCa channel blocker (big conductance)
Alternative Names: ChTx
Datasheet
Citations (4)
Literature

Biological Activity

Specific inhibitor of the big conductance Ca2+-activated K+ channel.

Technical Data

M. Wt 4295.95
Formula C176H277N57O55S7
Sequence XFTNVSCTTSKECWSVCQRLHNTSRGKCMNKKCRCYS

(Modifications: X-1 = Glp, Disulfide bridge between 7 - 28, 13 - 33,17 - 35, Ser-37 = C-terminal OH)

Storage Desiccate at -20°C
CAS Number 95751-30-7
PubChem ID 102594130
InChI Key CNVQLPPZGABUCM-UHFFFAOYSA-N
Smiles [H]N1[C@@H](CCC1=O)C(=O)N[C@@H](CC1=CC=CC=C1)C(=O)N[C@@H]([C@@H](C)O)C(=O)N[C@@H](CC(N)=O)C(=O)N[C@@H](C(C)C)C(=O)N[C@@H](CO)C(=O)N[C@H]1CSSC[C@@H]2NC(=O)[C@H](CCCCN)NC(=O)CNC(=O)[C@H](CCCNC(N)=N)NC(=O)[C@H](CO)NC(=O)[C@@H](NC(=O)[C@H](CC(N)=O)NC(=O)[C@H](CC3=CNC=N3)NC(=O)[C@H](CC(C)C)NC(=O)[C@H](CCCNC(N)=N)NC(=O)[C@H](CCC(N)=O)NC(=O)[C@@H]3CSSC[C@H](NC(=O)[C@H](CCCNC(N)=N)NC(=O)[C@H](CSSC[C@H](NC(=O)[C@H](CCC(O)=O)NC(=O)[C@H](CCCCN)NC(=O)[C@H](CO)NC(=O)[C@@H](NC(=O)[C@@H](NC1=O)[C@@H](C)O)[C@@H](C)O)C(=O)N[C@@H](CC1=CNC4=C1C=CC=C4)C(=O)N[C@@H](CO)C(=O)N[C@@H](C(C)C)C(=O)N3)NC(=O)[C@H](CCCCN)NC(=O)[C@H](CCCCN)NC(=O)[C@H](CC(N)=O)NC(=O)[C@H](CCSC)NC2=O)C(=O)N[C@@H](CC1=CC=C(O)C=C1)C(=O)N[C@@H](CO)C(O)=O)[C@@H](C)O

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

All Tocris products are intended for laboratory research use only.

Solubility Data

SolubilitySoluble to 1 mg/ml in water

Preparing Stock Solutions

The following data is based on the product molecular weight 4295.95. Batch specific molecular weights may vary from batch to batch due to solvent of hydration, which will affect the solvent volumes required to prepare stock solutions.

Select a batch to recalculate based on the batch molecular weight:
Concentration / Solvent Volume / Mass 1 mg 5 mg 10 mg
1 mM 0.23 mL 1.16 mL 2.33 mL
5 mM 0.05 mL 0.23 mL 0.47 mL
10 mM 0.02 mL 0.12 mL 0.23 mL
50 mM 0 mL 0.02 mL 0.05 mL

Molarity Calculator

Calculate the mass, volume, or concentration required for a solution.
=
x
x
g/mol

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and SDS / CoA (available online).

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Dilution Calculator

Calculate the dilution required to prepare a stock solution.
x
=
x

Product Datasheets

Certificate of Analysis / Product Datasheet
Select another batch:
Safety Datasheet

References

References are publications that support the products' biological activity.

Asano et al (1993) Charybdotoxin-sensitive K+ channels regulate the myogenic tone in the resting state of arteries from spontaneously hypertensive rats. Br.J.Pharmacol. 108 214 PMID: 7679030

Gimenez-Gallego et al (1988) Purification, sequence, and model structure of charybdotoxin, a potent selective inhibitor of calcium activated potassium channels. Proc.Natl.Acad.Sci.U.S.A. 85 3329 PMID: 2453055

Miller et al (1985) Charybdotoxin, a protein inhibitor of single Ca2+ activated K+ channels from mammalian skeletal muscle. Nature 313 316 PMID: 2578618


If you know of a relevant reference for Charybdotoxin, please let us know.

View Related Products by Product Action

View all Calcium-Activated Potassium (KCa) Channel Blockers

Keywords: Charybdotoxin, supplier, K+, channel, blockers, high, conductance, Ca2+-dependent, Potassium, KCa, Channels, ca2+-activated, ca2+-dependent, venoms, ChTx, Ca2+-Activated, Potassium, Channels, Tocris Bioscience

4 Citations for Charybdotoxin

Citations are publications that use Tocris products. Selected citations for Charybdotoxin include:

Thompson et al (2015) Small-conductance calcium-activated potassium (SK) channels in the amygdala mediate pain-inhibiting effects of clinically available riluzole in a rat model of arthritis pain. BMC Dermatol 11 51 PMID: 26311432

Mannowetz et al (2013) Slo1 is the principal potassium channel of human spermatozoa. Elife (Cambridge) 2 e01009 PMID: 24137539

Ohya et al (2011) Involvement of dominant-negative spliced variants of the intermediate conductance Ca2+-activated K+ channel, K(Ca)3.1, in immune function of lymphoid cells. J Biol Chem 286 16940 PMID: 21345794

Manaves et al (2004) Calcium and Vitamin D increase mRNA levels for the growth control hIK1 channel in human epidermal keratinocytes but functional channels are not observed. Sci Rep 4 7 PMID: 15200683


Do you know of a great paper that uses Charybdotoxin from Tocris? If so please let us know.
